CR-150-R6 Evaluation Board for CR-11X Charge Sensitive preamplifier modules
4.7 (76 items)
Limited Time SaleUS$74.40 cheaper than the new price!!
Free cash-on-delivery fees for purchases over $99
Product details
| Management number | 212361824 | Release Date | 2026/04/06 | List Price | US$49.60 | Model Number | 212361824 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
The CR-150-R6 prototyping test board will aid the experimenter in using and evaluating Cremat's charge sensitive preamplifiers (CSPs). The board has an 8-pin socket for the insertion of the CSP module, as well as power connectors, a power supply regulation circuit and other components needed to filter the detector bias. The CR-150-R6 can be used with any of Cremat's CSP modules: CR-110, CR-111, CR-112, and CR-113. Cremat’s shaping amplifier modules (CR-200 series) are NOT compatible with this board.
- Does not include CR-11X charge sensitive preamplifier module, housing, or power supply
- power requirements: +/-8V to +/-13V or alternatively use the 24V wall mount power supply CR-24V (sold separately).
- Die-cast aluminum housings are available for this board: CR-150-BOX-R6, CR-150-BOX-R6-HV, or CR-150-BOX-NoBias
- Specifications and full assembly instructions are at cremat.com
| Item Weight | 4.5 ounces |
|---|---|
| Manufacturer | Cremat Inc |
| Item model number | CR-150-R6 |
| Product Dimensions | 2.99 x 5 x 2.01 inches |
